Shaft Seal Kits
Shaft seals protect the motor and its bearings against dust or water entering through the shaft opening.
MS Connector Kits
Wire and Contact Sizing Recommendations
The following connector contact sizes and minimum wiring gages are recommended for cabling to
a motor.
Factory manufactured power cables and encoder cables are available in standard cable lengths of 10,
25, 50 and 75 feet (3, 7.6, 15 and 23 meters).
MOTOR SEAL KITS
MOTOR SERIES PART NUMBER
SIZE
(O Dia x I Dia x Width)
F-4000 0041-5060 1.437” x 0.875” x 0.25” (36mm x 22mm x 6mm)
F-6000 0041-5061 2.125” x 1.438” x 0.31” (54mm x 37mm x 8mm)
NOTE: Shaft seals are manufactured to inch dimensions. Millimeter dimensions are conversions from inches. Shaft seals require a
lubricant to reduce wear.
MOTOR POWER CONNECTORS
STRAIGHT MOTOR SERIES RIGHT ANGLE
9101-0326
(MS3106F20-4S)
F-4000 9101-0399
(MS3108F20-4S)
9101-0327
(MS3106F24-22S)
F-6000 9101-0400
(MS3108F24-22S)
BRAKE POWER CONNECTORS ENCODER FEEDBACK CONNECTORS
STRAIGHT STRAIGHT
9101-0330
(MS3106F12S-3S)
9101-0329
(MS3106F20-29S)
RIGHT ANGLE RIGHT ANGLE
9101-0403
(MS3108F12-3S)
9101-0402
(MS3108F20-29S)
POWER CONNECTOR ENCODER CONNECTOR
MOTOR
CONTACT
AWG(mm 2 )
WIRE
AWG(mm 2 )
CONTACT
AWG(mm 2 )
WIRE
AWG(mm 2 )
F-4030 12 (3.0) 16 (1.5) All F-Series
16 (1.5) 24 (0.25) with ULTRA Plus
F-4050 14 (2.5) 22 (0.34) with ULTRA 100-200
Drives
F-4075
F-6100 8 (8.6) 12 (4)
F-6200 8 (10) BRAKE CONNECTOR
F-6300 CONTACT
AWG(mm 2 )
WIRE
AWG(mm 2 ) Sizes are recommended minimum values for 4 conductors (R, S, T
and GND). Wiring should be twisted. Local regulations should always
be observed.
16 (1.5) 18 (0.75)
Recommended minimum mechanical size.
Local regulations should always be observed.
