44

Rockwell Automation Publication 1608M-UM004A-EN-P - April 2014

Chapter 7

Maintenance

64

ER_CAP_OV

ER Capacitor Over-Voltage

User Attention

Unit

The voltage of a capacitor in the ER cabinet
exceeded the maximum voltage rating. ER
cabinet disconnected.

Verify line voltage is within ratings. Verify proper
DySC application. Call service.

65

ER_FUSE

ER Cabinet Fuse Open

Call Service

Unit

One of the fuses in the ER cabinet was detected
open. ER cabinet disconnected.

Call service.

66

ER_UNBAL

ER Cabinet DC Bus Unbalance

Call Service

Unit

Positive and negative halves of the DC bus are
not equal. ER cabinet disconnected.

Call service.

67

ER_CAP_OT

ER Capacitor Over-Temperature

User Attention

Unit

The temperature of one of the capacitors in the
ER cabinet exceeded the maximum rating. ER
cabinet disconnected.

Verify ambient temperature is within DySC
specification. Check for damaged ER cabinet fans.
Check for dirty or obstructed air filters in the ER
cabinet.

68

ER_CAB_OT

ER Cabinet Over-Temperature

User Attention

Unit

ER cabinet internal air temperature exceeded
maximum rating. ER cabinet disconnected.

Verify ambient temperature is within DySC
specification. Check for damaged ER cabinet fans.
Check for dirty or obstructed air filters in the ER
cabinet.

69

GND_FLT

DySC Ground Fault

Call Service

Unit

Ground (Earth) fault was detected in the DySC.

Call service.

70

PLC_AN_ERR

PLC Analog Input Error

Call Service

PLC

Programmable logic controller analog input
channel error.

Call service.

71

ER_ST_MM

ER Cabinet PLC State Mismatch

Call Service

Unit

Programmable logic controller analog input
channel error.

Call service.

Event Code

Code Name

Full Name

Severity

Area

Event Description

Event Resolution
