IV. Compatibility for Combination I/O Modules
Table 2B: Conversion Cables for Bulletin 1771-N Series I/O Combination Modules
1771
Analog I/O Module
1756
Analog I/O Module
1492
"A" and "B" Cables
1492
Cable Descripton
1756- IF6I (Qty 1) “A” Cable = 1492- CONACAB020N7 Voltage
1756- IT6I (Qty 1) Thermocouple
1 771-NIVR
1 771-NIVT
1 771-NIVT
1756- IF6I (Qty 1)
1756- IF6I (Qty 1)
Current
1756- IT6I (Qty 1) Thermocouple
1771-NIVR
1756- IR6I (Qty 1) “B” Cable = 1492- CONACAB020N4
“A” Cable = 1492- CONACAB020N3
“B” Cable = 1492- CONACAB020N4
“A” Cable = 1492- CONACAB020N7
“B” Cable = 1492- CONACAB020N5
“A” Cable = 1492- CONACAB020N3
“B” Cable = 1492- CONACAB020N5
RTD
1756- IR6I (Qty 1) RTD
Voltage
1756- IF6I (Qty 1) Current
PN-107134
DIR 10000165561 (Version 01)
Publication 1492-IN104B-EN-E
Foot Notes:
To understand any issues concerning I/O module compatibility refer to the Installation Manuals for the specific I/O
modules involved.
Two conversions are possible using these two cables - (4 Voltage & 4 RTD) or (4 Current & 4 RTD) - see the Wiring
Diagrams for further details.
Two conversions are possible using these two cables - (4 Voltage & 4 Thermocouple) or (4 Current & 4 Thermocouple) -
see the Wiring Diagrams for further details.
These catalog numbers are for a 2.0M cable length. A 5.0M cable is also available. Change the 3 numerals in the
middle of the catalog number from "020" to "050" (Example: 1492-CONACAB020N1 becomes 1492CONACAB050N1).
Only 2 cables can be used at one time. Each cable attaches to 1 of the 2 connectors on the existing RTP module. Each
cable converts 4 of the 1771 channels to 4 of the 1756 channels. The other end of the cable attaches to 1 of the 2 new
1756 modules.
