20

Publication 283D-QS001C-EN-P - July 2006

Bulletin 283 Parameters

Table 9

Starter Display and Parameter Settings

Table 10 FLA Setting Ranges and Default Values (with indicated setting precision)

Parameter

Name String

Path (hex)

Min

Max

Dflt

Type

Value

SMC Display

101

Phase A Current

002C – 01 – 08

0

32767

INT

xxx.x Amps

102

Phase B Current

002C – 01 – 09

0

32767

INT

xxx.x Amps

103

Phase C Current

002C – 01 – 0A

0

32767

INT

xxx.x Amps

104

Average Current

002C – 01 – 05

0

32767

INT

xxx.x Amps

105

% Therm Utilized

002C – 01 – 07

0

100

USINT

xxx %

SMC Settings

106

FLA Setting

002C – 01 – 03

See Table 10 below

Min I

INT

xxx.x Amps

107

OL Trip Class

002C – 01 – 04

0

3

1

BYTE

1 = 10

108

OL Reset Level

0029 – 01 – 131

0

100

75

BYTE

xxx %

109

Start Time

000F - 06D - 01

1

45

10

USINT

sec

110

Start Mode

000F - 06E - 01

0

1

0

BOOL

0 = Current Limit

1 = Soft Start

111

Current Limit

000F - 06 - 01

150

600

350

UINT

xxx % FLA

Display multiplier of 10.

SMC is looking for values

between 15 and 60.

112

Initial Torque

000F - 070 - 01

0

90

60

USINT

% LRT

113

Soft Stop Time

000F - 071 - 01

0

90

0

USINT

sec

114

Kick Start

000F - 072 - 01

0.0

1.5

0.0

USINT

sec

115

SCR Temp Reset Mode

000F - 073 - 01

0

1

0

BOOL

0 = Manual

1 = Auto Reset

116

Phase Rotation

000F - 074 - 01

0

1

0

BOOL

0 = Disable

1 = Enable

FLA Current Range (A)

Default Value

Minimum Value

Maximum Value

1.1

3.0

1.1

3.0

5.5

3.0

5.3

7.6

5.3

6.3

16.0

6.3
