16

Publication 283D-QS001C-EN-P - July 2006

Table 3

Default I/O Messaging Data

Default Input and Output (I/O) Assembly Formats

The I/O assembly formats for the ArmorStart

are identified by the value in

parameter 11 (Consumed IO Assy.) and parameter 12 (Produced IO Assy.).
These values determine the amount and arrangement of the information
communicated to the master scanner. The tables below identify the default
information produced and consumed by the Bulletin 283 devices. For
additional formats and advance configurations please reference the user
manual:

Defaults for Standard Distributed Motor Controllers

Table 4

Instance 160 - Default Consumed data for Standard Distributed Motor

Controller Output information arrangement (1 byte)

Table 5

Instance 161 - Default Produced data for Standard Distributed Motor

Controller Input information arrangement (2 bytes)

Default

Message type

Polled

Consumed data size

1 byte (Rx)

Produced data size

2 bytes (Tx)

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

0

User Out

B

User Out

A

Not

Used

Not

Used

Not

Used

Fault

Reset

Run Fwd

Byte

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

0

Not

Used

Not

Used

Not

Used

Ready

Running

Fwd

Warning

Tripped

1

Not

Used

Not

Used

140M

On

HOA

Status

User In 3 User In 2

User In 1

User In 0
