Publication 700-IN003C-EN-P - October 2009
4 Bulletin 700 Type RTC & RTCR Solid-State Relays
Table 1 Timer Operation
Note:
When the timer is energized or times out in the on-delay mode, an
N.O. contact may close before an N.C. contact opens; this can occur because
of inherent operating characteristics. Similarly, when the timer is de-energized
or times out in the off-delay mode, an N.C. contact may close before an N.O.
opens. Assured contact overlap or non-overlap cannot be provided in the same
device.
Terminals
Terminal clamps are designed for solid or stranded copper wire (strip ends to
7.9mm [5/16”]). Use 7 - 8 lb.-in. of torque to tighten the terminal clamps. Wire
size: (1) #18 AWG (.75mm
2
) minimum to (2) #12 AWG (14.0mm
2
)
maximum.
Wiring
Make connections as shown in Figure 3. Power is applied continuously to
terminals L1 and L2. Voltage applied and removed at initiating terminal P will
operate the instantaneous contacts and initiate timing as indicated in Table 1.
Use insulated copper wire rated at 75
°
C (167
°
F) or higher.
Operating
Mode
Power
(Terminals
L1-L2)
Voltage
(Applied to
Initiate
Terminal P)
Timer Status
Red LED
Indicator
Contact Cartridge Statue
Instantaneous
Timed
N.O
N.C
N.O
N.C
On-delay
On
No
Reset
Off
Open
Closed
Open
Closed
Yes
Timing
Flashing
Closed
Open
Open
Closed
Yes
Timed Out
On
Closed
Open
Closed
Open
Off
No
Stable
Off
Open
Closed
Open
Closed
Yes
Stable
Off
Closed
Open
Open
Closed
Off-delay
On
Yes
Reset
On
Closed
Open
Closed
Open
No
Timing
Flashing
Open
Closed
Closed
Open
No
Timed Out
Off
Open
Closed
Open
Closed
Off
No
Stable
Off
Open
Closed
Open
Closed
Yes
Stable
Off
Closed
Open
Open
Closed
