Rockwell Automation 825 Current Monitoring Modules - Manual (Page 5)

Technical changes reserved
25.712.921-01 / 07. 2003
Edition 5
b = max. 25 mm (1")
ø = min. 11 mm (7/16")
c = max. 12,5 mm (1/2")
s = max. 8 mm (5/16")
DIN 46234
b = max. 25 mm (1")
ø = min. 11 mm (7/16")
c = max. 8 mm (5/16")
T = 10...12 Nm
Anschlüsse
Conexiones
Connections
Raccordements
Collegamenti
Anschlüsse
Conexiones
Connections
Raccordements
Collegamenti
s
ø b
ø b
c
s
825-MCM420
825-MCM630
Dimensions in mm (inches)
48 (1- 7/8)
135 (5- 5/16)
155 (6- 7/64)
118 (4- 41/64)
156 (6- 9/64)
158
6,3 (1/4)
ø 11 (7/16)
M 10
ø 6,3 (1/4)
88
(
3-
1
5/
32
)
14
5
(
5-
4
5/
64
)
48 (1- 7/8)
b = max. 25 mm (1")
ø = min. 10.5 mm (13/32")
c = max. 12.5 mm (1/2")
s = max. 8 mm (5/16")
DIN 46234
b = max. 25 mm (1")
ø = min. 10.5 mm (13/32")
c = max. 8 mm (5/16")
T = 10...12 Nm
s
ø b
ø b
c
s
6,5
(1/4)
155 (6- 7/64)
135 (5- 5/16)
14
3
(
5-
5
/8
)
118,4 (4- 21/32)
M10
72 (2- 27/32)
174,6 (6- 7/8)
177,2 (6- 31/32)
10.5
(13/32)
48
(1- 7/8)
48
(1- 7/8)
90
...
93
(3
-
35
/6
4.
..3
-
21
/3
2)
6,5
(1/4)
Dimensions in mm (inches)
825-MCM630N
