183 Specifications
Media Specifications
1/11/07 X-Plus II User Guide 14068L-001 Rev. A
BP-300X-Plus II and 600X-Plus II Black Mark Sensing Only
BP-360X-Plus II Printers
Media Specifications BP-300X-Plus II BP-600X-Plus II
Mark length (measuring parallel to
label/tag edge) Minimum 0.12 in. (3 mm) 0.12 in. (3 mm)
Maximum 0.43 in. (11 mm) 0.43 in. (11 mm)
Mark width (measuring to
perpendicular label/tag edge) Minimum 0.43 in. (11 mm) 0.43 in. (11 mm)
Maximum Full media width Full media width
Mark location within 0.040 in. (1 mm)
of the inside media edge within 0.040 in. (1 mm)
of the inside media edge
Mark density in Optical Density Unit (ODU) >1.0 >1.0
Media Specifications BP-360X-Plus II
Minimum label length Tear-Off 0.7 in. (18 mm)
Peel-Off 0.5 in. (13 mm)
Cutter 1.5 in. (38 mm)
Rewind 0.25 in. (6 mm)
Total media width (label + backing, if any) Minimum 2.00 in. (51 mm)
Maximum 7.1 in. (180 mm)
Total thickness (includes backing, if any) Minimum 0.003 in. (0.076 mm)
Maximum 0.012 in. (0.305 mm)
Cutter maximum full-width media thickness 0.007 in. (0.18 mm)
Roll media core inside diameter 3 in. (76 mm)
Maximum roll diameter 8.0 in. (203 mm)
Inter-label gap Minimum 0.079 in. (2 mm)
Maximum 0.118 in. (3 mm)
Maximum internal fanfold media pack size
(label + backing) L×W×H 8.0Ч7.1Ч4.5 in.
(203Ч114Ч114 mm)
Ticket/tag sensing notch LЧW 0.12Ч0.25 in.(3×6 mm)
Ticket/tag sensing hole diameter 0.125 in.(3 mm)
Effective leading edge registration accuracy (vertical) ± 0.060 in. (± 1.5 mm)
Effective leading edge registration accuracy (horizontal) ± 0.060 in. (± 1.5 mm)
