Data Ports
Applicator Interface Connector
172
14178L-001 Rev. A
T408M/T408M-R User Guide
1/11/07
13
RIBBON OUT
Output
Asserted LOW while there is no ribbon in the printer.
14
DATA READY
Output
Applicator Signals on page 168
about this signal.
• Asserted LOW when sufficient data has been received
to begin printing the next label.
• Deasserted HIGH whenever printing stops after the
current label, due to either a pause condition or the
absence of a label format.
Table 20 • Applicator Interface Connector Pin Configuration (Continued)
