Page 3

110V bulb for conduit beacon indicator
Pt. No: 09055
240V bulb for conduit beacon indicator
Pt. No: 09054
24V bulb for conduit beacon indicator
Pt. No: 09056
M20 Conduit beacon indicator - Amber
Pt. No: 19001
M20 Conduit beacon indicator - Red
Pt. No: 19002
Pg13.5 Conduit beacon indicator - Amber
Pt. No: 19003
1/2" NPT Conduit beacon
Pt. No: 19005
Lamplighter
Pt. No: 09075
Glühlampe 24 V
Bestell-Nr. 09056
Glühlampe 230 V
Bestell-Nr. 09054
Leuchtenaufsatz
Bestell-Nr. 09075
110V Lampes pour verrine
Ref: 09055
240V Lampes pour verrine
Ref: 09054
24V Lampes pour verrine
Ref: 09056
M20 lampe de signalisation orange
Ref: 19001
M20 lampe de signalisation orange
Ref: 19002
Pg13.5 lampe de signalisation orange
Ref: 19003
Presse étoupe 1/2" NPT
Ref: 19005
Verrine pour Rotacam
Ref: 09075
ZUBEHÖR
(x1)
ACCESSORIES
ACCESSORIES
(w1)
Technical Specifications
Conforming to standards
EN 60947-5-1, EN 1088,
EN 292, EN 60204-1.
Contact arrangement
2N/C + 1N/O positive break.
Utilisation cat.
AC 15.
a.c (Ue)
500 V 25V 100V
(le)
1A 2A 5A.
d.c
250V 0.5A, 24V 2A.
Thermal current (lth)
10A.
Minimum current
5V 5mA DC.
Safety contact gap
>2 x 2mm.
Rtd. insulation voltage
(Ui) 500V.
Rtd. impulse withstand voltage
(Uimp) 2500V.
Pollution degree
3.
Shaft rotation to achieve contact
operation
5
°
min - 11
°
max adjustable.
Break contact min . force
12N.
Max. actuation speed
160mm per sec.
Max. actuation frequency
1 Cycle per sec.
Case material
Heavy duty die cast alloy.
Actuator shaft
Stainless Steel.
Protection
IP 66 earthed.
Conduit entry
1 x M20 (Pg11 or 1/2"NPT
also available).
Operating temperature
-25
°
C to +80
°
C.
Fixing
2 x M4 (Optional 2 x M5 tapped from rear)
Mechanical life
>1 x 10
6
.
Electrical life
>1 x 10
6
.
Weight
420g.
Colour
Red.
EX Specifications
Classification
EExd IIc T6.
Contact arrangement
1N/C + 1N/O or 2N/C.
Protection
IP66.
Rated voltage
250V AC / 250V DC.
Rated current
5A AC / 0.25A DC / 0.4ADC.
AC ratings
250V
125V
resistive
6A
6A
inductive
2.5A
3A.
DC ratings
250V
125V 30V
resistive
0.25A
0.5A 7A
inductive
0.1A
0.2A 5A.
Mechanical life
2x10
6
.
Electrical life
dependent on loading.
Ambient temperature
-25
°
C to +70
°
C.
Electrical connection
Potted leads. Flexible 4x0.75mm
2
,
2m long.
Pneumatic Specifications
Fluid used
Compressed air or inert gas.
Pressure range
2 to 8 bars.
Passage diameter
2.7mm.
Connection
Push in fittings for standard 4mm Ø
nylon tube, internal Ø 2.5mm.
Flow
138 NL/min. (ie. no. of litres of air at
normal atmospheric pressure obtained
with the output open to atmosphere &
the supply pressure at 4 bars).
Mechanical endurance
>1 x 10
6
.
Temperature
-10
°
C to +60
°
C.
Normen
EN 60947-5-1, DIN EN 1088, DIN EN 292
Gehäusematerial
Leichtmetall-Druckguß, rot lackiert
Wellenmaterial
Nichtrostender Stahl
Gehäusebefestigung
4 x M4-Schrauben (plus ggf.
x M5-Gewinde)
Deckelschrauben
4 Sicherheitsschrauben (TORX m. Stift)
Montagelage
Beliebig
Schutzart
IP 66
Leitungseinführung
Pg 11 (oder M20 ISO)
Kontakte
2 Ö + 1 S
Kontaktöffnungsweite
> 2 x 2 mm
Öffnungskraft Kontakte
≥
12 N
Bemessungsstoßspannungsfestigkeit
Uimp
2500 V
Bemessungsisolationsspannung Ui
500 V
Bemessungsbetriebsstrom le (AC-15) 1 A / 500 VAC, 2 A / 250 VAC,
5 A 100 VAC
Minimaler Strom
5 mA (5 V)
Kurzschlußfestigkeit
6 A (träg), zwangsöffnender Öffner
Schaltwinkel
5 bis 11
°
einstellbar
Betätigungsfrequenz
Max. 1 / s
Betätigungsgeschwindigkeit
Max. 160 mm/s
Betriebstemperatur
-25 bis +80
°
C
Mech. Lebensdauer
> 10
6
Schaltspiele
Gewicht
420 g
Rotacam EX
Explosionsschutz
EEx d llC T6
Gehäuseschutzart
IP 66
Kontakte
1 Ö + 1 S oder 2 Ö
Nennspannung
250 VAC/DC
Nennstrom
5 AAC/0,4 ADC
Schaltleistung AC
250 V 125 V
ohmsch
6A 6A
induktiv
2,5 A 3 A
Schaltleistung DC
250 V 125 V 30 V
ohmsch
0,25 A 0,5 A 7 A
induktiv
0,1 A 0,2 A 5 A
Elektrischer A nschluß
Leitung H05VV-F, 4 x 0,75 mm
2
, 2 m
Betriebstemperatur
-25 bis +70
°
C
Mech. Lebensdauer
> 2 x 10
6
Elektr. Lebensdauer
Abhängig von der Belastung
Rotacam Pneumatic
Fluid
Druckluft oder neutrales Gas
Druckbereich
2 bis 8 bar
Durchmesser Durchgang
2,7 mm
Anschluß
Steckanschlüsse für Standard-Nylonrohr
4 mm Ø, Innen-Ø 2,5 mm
Durchfluß
138 NI/min (d.h. Liter Luft bei
normalem Atmosphärendruck und
offenem Ausgang zur Atmosphäre und
Eingangsdruck 4 bar)
Betriebstemperatur
-10 bis +60
°
C
Mech. Lebensdauer
> 1 x 10
6
Conforme aux normes
EN 60947-5-1, EN 1088, EN 292,
EN 60204-1
Contacts disponibles
2 N/C + 1 N/O à fonctionnement positif
Catégorie
AC15
a.c (Ue)
500V 250V 100V
(le)
1A 2A 5A
d.c
250V-0,5A / 24V-2A
Courant thermique (lth)
10A
Courant minimum
5V-5mA DC
Enclenchement des contacts de sécurité >2mm
Tension efficace
(Ui) 500V
Tension d'isolement
(Uimp) 2500V
Degré de pollution
3
Angle de basculement des contacts
Rélable de 5
°
à 11
°
maximum
Force minimum de rupture des contacts 12N
Vitesse d'ouverture
160mm par seconde
Fréquence d'ouverture
1 cycle par seconde
Boîtier
métal robuste
Axe
Acier inoxydable
Indice de protection
IP66
Presse-étoupe
1 x M20 ou 1 x Pg11 ou 1/2 NOT
Température d'utilisation
-25
°
C à 80
°
C
Fixations
2 x M4
Durée de vie mécanique
1000000 manoeuvres
Durée de vie électrique
1000000 manoeuvres
Poids
420grs
Couleur
Rouge
VERSION ANTI-DEFLAGRANTE
classification
EExdllcT6
Contacts
1 N/C + 1 N/O ou 2 N/C
Indice de protection
IP66
Tension
250VAC / 250 VDC
Courant
5A AC / 0.25A DC / 0.4 ADC
Gamme Tension AC
250V 150V
Intensité résistive
6A 6A
Intensité inductive
2.5A 3A
Gamme Tension DC
250V 150V 75V 30V
Intensité résistive
0.25A 0.5A 1A 7A
Intensité inductive
0.1A 0.2A 1A 5A
Durée de vie mécanique
2000000 manoeuvres
Durée de vie électrique
Dépend de la charge
Température ambiante
-25
°
C à + 70
°
C
Connexions
Précâblé en 2 mètres, 4 x 0.75mm
2
VERSION PNEUMATIQUE
Fluide
Air comprimé ou gaz neutre
Pression
2 à 8 bars
Diamètre de passage
2,7mm
Connexions
par flexible tube nylon standard 4mm,
interne 2.5mm
Flux
138NL/min (le: pas un litre d'air obtenu
à pression atmosphérique normale avec
une sortie ouverte à l'air libre et une
pression d'alimentation de 4 bars
Durée de vie mécanique
>1000000 mécaniques
Température d'utilisation
-10
°
C à 60
°
C
Specifications Techniques
Technische Daten
