2-6 Installing the Adapter
1. Close the door or reinstall the cover on the drive. The status
indicators can be viewed on the front of the drive after power has
been applied.
2. Ensure that the adapter will have a unique address on the network
and is set at the correct data rate. If a new data rate or address is
needed, reset its switches (Refer to
Commissioning the Adapter in
this chapter.)
3. Apply power to the PowerFlex drive. The adapter receives its power
from the connected drive. When you apply power to the product for
the first time, the status indicators should be green after an
initialization. If there is a problem, refer to
Chapter 4 , Using
DriveExplorer on the RS-485 Network .
4. If the data rate switch is set to “PGM,” use a configuration tool to set
the data rate and node address parameters in the adapter ( Chapter 3 ,
Configuring the Adapter ).
5. Verify that the master and network are installed and functioning in
accordance with RS-485 DF1 standards.
Applying Power
!
ATTENTION: Risk of equipment damage, injury, or death exists.
Unpredictable operation may occur if you fail to verify that parameter
settings and switch settings are compatible with your application.
Verify that settings are compatible with your application before
applying power to the drive.
