Step 11: installing the drive covers – Rockwell Automation 20D DriveLogix Controller for PowerFlex 700S Phase I Drives User Manual
Page 15

DriveLogix Controller for PowerFlex 700S Phase I Drives
15
2. Connect the cable to the serial port on the DriveLogix Controller.
Step 11: Installing the Drive
Covers
Install the front and side covers on the drive in reverse order as detailed in
Step 2:
Removing the Covers from the Control Assembly on page 4
!
ATTENTION: If you connect or disconnect the serial cable
from the DriveLogix Controller with power applied to the
module or a connected serial device, an electrical arc can occur.
This could cause an explosion in hazardous location installations.
Verify that power is removed from the drive and module or that
the area is non-hazardous before proceeding.
TIP: Remember to route the cable through the sliding access panel at the
bottom of the Control assembly.
