64cr1, 64 series probe assemblies – Rockwell Automation 13DJ3 Liquid Level Controls User Manual
Page 13
13
Figure 14
2
(50.8)
1.125
(28.6)
.562 DIA.
(14.3)
.25 DIA.
(6.35)
1/4--20 UNC
.75
(19)
“A” DIM.
6
(152.4)
61--3284
.875 DIA. (22.2)
PROBE TIP
NO. 316 S.S.
INSULATED
1.25
(31.8)
.312 (7.9)
61--3285
ADAPTER
NO. 316 S.S.
7/16 HEX (11.1)
58--66
.281 DIA. (7.1)
NO. 16 S.S. WIRE,
INSULATED
WITH GEON
LENGTH TO BE
SPECIFIED BY
CUSTOMER
64CR1
1/4--20 NC2
HEX NUT,
NO. 316 S.S.
64 Series Probe Assemblies
