4
Wiring Diagrams
Cable
Brown: 12V-24V DC
Black: Output
Blue: -DC
Black: Output
Brown: 12V-24V DC
Cable
Blue: -DC
Cable
Load
NPN Output
PNP Output
Orange: Stability
Orange: Stability
+
-
Load
+
-
Quick-Disconnect
Brown
Black
Blue
1
3
4
Brown
Black
Blue
1
3
4
Orange 2
Orange 2
NPN Output
PNP Output
+
-
Load
Load
+
-
Dimensions
Receiver
Transmitter
9
(0.35)
5 (0.2)
4.7
(0.19)
3
(0.12)
30
(1.18)
9
(0.35)
4 (0.16) 60 (2.36) 3
(0.12)
3
(0.12)
4.8
(0.19)
Dia.
4 (0.16)
21 (0.83)
16
(0.63)
36.5 (1.44)
11.5
(0.45)
2-3.2 (0.13)
Dia. hole
2-3.2 (0.13) x 5.2
(0.2) oval hole 21 (0.83)
16
(0.63)
Mounting Bracket
Cord
Bushing
Replacement Parts
S
Plastic Sensor Cover : PSC1
S
Fiber Optic Cable (Diffuse) : 99–94
S
Fiber Optic Cable (Transmitted Beam) : 99–90
S
Pico QD Cordset : 889P–F4AB–2
S
Power Bus QD Connectors:
2 Conductor = 45F–A2C–A2
4 Conductor = 45F–A4C–A2
S
Power Bus End Caps:
Male Cap = 45F–AMC
Female Cap = 45F–AFC
Publication 75009–137–01(B)
May 2002
Printed in USA
PHOTOSWITCHR is a registered trademark
of Rockwell Automation.
