Refer to the PowerFlex 40P User Manual for details on how to comply
with the Low Voltage (LV) and Electromagnetic Compatibility (EMC)
Directives.
Drive Ratings
CE Conformity
Specifications, Fuses and Circuit Breakers
Catalog
Number
(1)
Output Ratings
Input Ratings
Branch Circuit Protection
kW (HP)
Amps
Voltage
Range
kVA
Amps
Fuses
140M Motor
Protectors
(2)
(3)
Contactors
Min. Enclosure
Volume
(4)
(in.
3
)
200 - 240V AC (±10%) – 3-Phase Input, 0 - 230V 3-Phase Output
22D-B2P3
0.4 (0.5)
2.3
180-264
1.15
2.5
6
140M-C2E-B40
100-C07
1655
22D-B5P0
0.75 (1.0)
5.0
180-264
2.45
5.7
10
140M-C2E-C10
100-C09
1655
22D-B8P0
1.5 (2.0)
8.0
180-264
4.0
9.5
15
140M-C2E-C16
100-C12
1655
22D-B012
2.2 (3.0)
12.0
180-264
5.5
15.5
25
140M-C2E-C16
100-C23
1655
22D-B017
3.7 (5.0)
17.5
180-264
8.6
21.0
30
140M-F8E-C25
100-C23
1655
22D-B024
5.5 (7.5)
24.0
180-264
11.8
26.1
40
140M-F8E-C32
100-C37
2069
22D-B033
7.5 (10.0)
33.0
180-264
16.3
34.6
60
140M-G8E-C45 100-C60
2069
380 - 480V AC (±10%) – 3-Phase
Input, 0 - 460V 3-Phase Output
22D-D1P4
0.4 (0.5)
1.4
342-528
1.4
1.8
3
140M-C2E-B25
100-C07
1655
22D-D2P3
0.75 (1.0)
2.3
342-528
2.3
3.2
6
140M-C2E-B40
100-C07
1655
22D-D4P0
1.5 (2.0)
4.0
342-528
4.0
5.7
10
140M-C2E-B63
100-C09
1655
22D-D6P0
2.2 (3.0)
6.0
342-528
5.9
7.5
15
140M-C2E-C10
100-C09
1655
22D-D010
4.0 (5.0)
10.5
342-528
10.3
13.0
20
140M-C2E-C16
100-C23
1655
22D-D012
5.5 (7.5)
12.0
342-528
11.8
14.2
25
140M-D8E-C20
100-C23
2069
22D-D017
7.5 (10.0)
17.0
342-528
16.8
18.4
30
140M-D8E-C20
100-C23
2069
22D-D024
11.0 (15.0)
24.0
342-528
23.4
26.0
50
140M-F8E-C32
100-C43
2069
460 - 600V AC (±10%) – 3-Phase
Input, 0 - 575V 3-Phase Output
22D-E1P7
0.75 (1.0)
1.7
414-660
2.1
2.3
6
140M-C2E-B25
100-C09
1655
22D-E3P0
1.5 (2.0)
3.0
414-660
3.65
3.8
6
140M-C2E-B40
100-C09
1655
22D-E4P2
2.2 (3.0)
4.2
414-660
5.2
5.3
10
140M-D8E-B63
100-C09
1655
22D-E6P6
4.0 (5.0)
6.6
414-660
8.1
8.3
15
140M-D8E-C10
100-C09
1655
22D-E9P9
5.5 (7.5)
9.9
414-660
12.1
11.2
20
140M-D8E-C16
100-C16
2069
22D-E012
7.5 (10.0)
12.2
414-660
14.9
13.7
25
140M-D8E-C16
100-C23
2069
22D-E019
11.0 (15.0)
19.0
414-660
23.1
24.1
40
140M-F8E-C25
100-C30
2069
(1)
Ratings apply to all drive types; Panel Mount (N104), Flange Mount (F104), and Plate Drive
(H204).
(2)
The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See
(3)
Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240
Wye or Delta, 480Y/277 or 600Y/347. Not UL listed for use on 480V or 600V Delta/Delta, corner
ground, or high-resistance ground systems.
(4)
When using a Manual Self-Protected (Type E) Combination Motor Controller, the drive must be
installed in a ventilated or non-ventilated enclosure with the minimum volume specified in this
column. Application specific thermal considerations may require a larger enclosure.
