English-17
The PowerFlex 40P is designed so that start up is simple and efficient. The Program Group
contains the most commonly used parameters.
Display Group Parameters
No.
Parameter
Min/Max
Display/Options
b001 [Output Freq]
0.00/[Maximum Freq]
0.01 Hz
b002 [Commanded Freq]
0.00/[Maximum Freq]
0.01 Hz
b003 [Output Current]
0.00/(Drive Amps
×
2)
0.01 Amps
b004 [Output Voltage]
0/Drive Rated Volts
1 VAC
b005 [DC Bus Voltage]
Based on Drive Rating
1 VDC
b006 [Drive Status]
0/1 (1 = Condition True)
Bit 3
Bit 2
Bit 1
Bit 0
Decelerating
Accelerating
Forward
Running
b007-
b009
[Fault x Code]
F2/F122
F1
b010 [Process Display]
0.00/9999
0.01 – 1
b012 [Control Source]
0/112
Digit 4
Digit 2 & 3 = Speed Command
Reserved
01-11
Digit 1 = Start Command
1, 2 & 9
b013 [Contrl In Status]
0/1 (1 = Input Present)
Bit 3
Bit 2
Bit 1
Bit 0
DB Trans On
Stop Input
Dir/REV In
Start/FWD In
b014 [Dig In Status]
0/1 (1 = Input Present)
Bit 3
Bit 2
Bit 1
Bit 0
Digital In 4
Digital In 3
Digital In 2
Digital In 1
b015 [Comm Status]
0/1 (1 = Condition True)
Bit 3
Bit 2
Bit 1
Bit 0
Comm Error
DSI Option
Transmitting
Receiving
b016 [Control SW Ver]
1.00/99.99
0.01
b017 [Drive Type]
1001/9999
1
b018 [Elapsed Run Time]
0/9999 Hrs
1 = 10 Hrs
b019 [Testpoint Data]
0/FFFF
1 Hex
b020 [Analog In 0-10V]
0.0/100.0%
0.1%
b021 [Analog In 4-20mA]
0.0/100.0%
0.1%
b022 [Output Power]
0.00/(Drive Power
×
2)
0.01 kW
b023 [Output Powr Fctr]
0.0/180.0 deg
0.1 deg
b024 [Drive Temp]
0/120 degC
1 degC
b025 [Counter Status]
0/9999
1
b026 [Timer Status]
0.0/9999 Secs
0.1 Secs
b028 [Stp Logic Status]
0/8
1
b029 [Torque Current]
0.00/(Drive Amps
×
2)
0.01 Amps
Smart Start-Up with Program Group Parameters
= Stop drive before changing this parameter.
No.
Parameter
Min/Max
Display/Options
Default
P031 [Motor NP Volts]
20/Drive Rated Volts
1 VAC
Based on Drive Rating
Set to the motor nameplate rated volts.
P032 [Motor NP Hertz]
15/500 Hz
1 Hz
60 Hz
Set to the motor nameplate rated frequency.
P033 [Motor OL Current]
0.0/(Drive Rated Amps
×
2) 0.1 Amps
Based on Drive Rating
Set to the maximum allowable motor current.
P034 [Minimum Freq]
0.00/500.0 Hz
0.01 Hz
0.00 Hz
Sets the lowest frequency the drive will output
continuously.
P035 [Maximum Freq]
0.00/500.0 Hz
0.01 Hz
60.00 Hz
Sets the highest frequency the drive will output.
