WI-I/O-EX Serial I/O Module User Manual v1.11
Page 46 February 2010
Data ModBus I/O Type ModBus
Addresses
Analog inputs 2 Input registers 30002
Analog inputs 3 Input registers 30003
Analog inputs 4 Input registers 30004
Analog inputs 5 Input registers 30005
Analog inputs 6 Input registers 30006
Analog inputs 7 Input registers 30007
Analog inputs 8 Input registers 30008
Module supply voltage * Input registers 30033
Analog supply voltage (24V) + Input registers 30034
Serial port transmission mode Input registers 30201
Serial port baud rate Input registers 30202
Serial port parity and stop bit Input registers 30203
* 0x4000 = 8V; 0xC000 = 16V
+ 0x4000 =12V; 0xC000 = 36V
