WI-I/O-EX Serial I/O Module
User Manual v1.11
Page 42
February 2010
5.4 Hexadecimal representation of voltage and current levels
The voltage and current levels are represented as a fraction of the configured scale. 4000
hex represents the minimum level in the scale, and C000 hex represents the maximum
level in the scale.
Levels and their hex representation are summarized in Table 5-1 for easy reference.
Voltage scale
Current scale
Hex
value
Percent
Dec
value
0-5V 0-10V 1-5V 0-10mA 0-20mA 4-20mA
0000
0.00%
0
N/A
N/A
N/A
N/A
N/A
N/A
0800
3.13%
2048
N/A
N/A
N/A
N/A
N/A
N/A
1000
6.25%
4096
N/A
N/A
N/A
N/A
N/A
N/A
1800
9.38%
6144
N/A
N/A
N/A
N/A
N/A
N/A
2000 12.50%
8192
N/A
N/A 0.00
N/A
N/A
0.00
2800 15.63% 10240
N/A
N/A 0.25
N/A
N/A
1.00
3000 18.75% 12288
N/A
N/A 0.50
N/A
N/A
2.00
3800 21.88% 14336
N/A
N/A 0.75
N/A
N/A
3.00
4000 25.00% 16384
0.00
0.00 1.00
0.00
0.00
4.00
4800 28.13% 18432
0.31
0.63 1.25
0.63
1.25
5.00
5000 31.25% 20480
0.63
1.25 1.50
1.25
2.50
6.00
5800 34.38% 22528
0.94
1.88 1.75
1.88
3.75
7.00
6000 37.50% 24576
1.25
2.50 2.00
2.50
5.00
8.00
6800 40.63% 26624
1.56
3.13 2.25
3.13
6.25
9.00
7000 43.75% 28672
1.88
3.75 2.50
3.75
7.50
10.00
7800 46.88% 30720
2.19
4.38 2.75
4.38
8.75
11.00
8000 50.00% 32768
2.50
5.00 3.00
5.00
10.00
12.00
8800 53.13% 34816
2.81
5.63 3.25
5.63
11.25
13.00
9000 56.25% 36864
3.13
6.25 3.50
6.25
12.50
14.00
9800 59.38% 38912
3.44
6.88 3.75
6.88
13.75
15.00
A000 62.50% 40960
3.75
7.50 4.00
7.50
15.00
16.00
A800 65.63% 43008
4.06
8.13 4.25
8.13
16.25
17.00
B000 68.75% 45056
4.38
8.75 4.50
8.75
17.50
18.00
B800 71.88% 47104
4.69
9.38 4.75
9.38
18.75
19.00
C000 75.00% 49152
5.00
10.00 5.00 10.00
20.00
20.00
C800 78.13% 51200
5.31
10.63 5.25 10.63
21.25
21.00
D000 81.25% 53248
5.63
11.25 5.50 11.25
22.50
22.00
D800 84.38% 55296
5.94
11.88 5.75 11.88
23.75
23.00
E000 87.50% 57344
6.25
12.50 6.00 12.50
N/A
24.00
E800 90.63% 59392
6.56
13.13 6.25 13.13
N/A
N/A
F000 93.75% 61440
6.88
13.75 6.50 13.75
N/A
N/A
Table 5-1: Hex representation of voltage and current levels.
