Technical Data
6-85
Electrical Data
Power supply
The power supply of the IE-GPRS-I/O must be
provided exclusively by a power pack which
complies with DIN EN 60742 or VDE 0551.
Rated operating voltage 10 … 36 VDC / 8 … 24 VAC
Rated operating capacity 5 W
Fuse, external T2A
Rated frequency 50 Hz ... 60 Hz
Redundancy Redundant power supply
Inputs/outputs
Digital inputs
- Input voltage range
12/24 VDC
0 … 30 V DC against GND of the same connector
Insulation voltage 500 V
Digital outputs
- Output voltage range 12/24 VDC
0 … 30 V DC against GND of the same connector
Insulation voltage 500 V
Analog inputs
- Input voltage range
- Input current range
- Temperature
0 … 10 V
Max. 30 V, input resistance 180 kOhm
Insulation voltage 500 V
0 … 20 mA
Max. 100 mA, input resistance 100 kOhm
Insulation voltage 500 V
PT1000
Insulation voltage 500 V
RS232 EIA RS-232-C/CCITT V.24 to 38.4 Kbit/s
1 DCD Received Line Signal - Data Carrier Detect
2 RxD Received Data
3 TxD Transmitted Data
4 DTR Data Terminal Ready
5 GND Signal Ground/Common Return
6 DSR Data Set Ready
7 RTS Request to Send
8 CTS Clear to Send
9 RING Ring Indicator
Wireless GSM/GPRS 900/1,800MHz
Asynchronous, full/half-duplex or simplex
General specifications
Error messages Via GSM if configured
