Weidmuller GPRS Alarm Unit - Manual (Page 84)

Hardware
5-82
Pin assignment of the terminal on the device upperside
GND GND3 Digital earth signal digital in 5 … 8 GND
7 DI5 0 ... 30 V DC signal digital in 5
8 DI6 0 ... 30 V DC signal digital in 6
9 DI7 0 ... 30 V DC signal digital in 7
10 DI8 0 ... 30 V DC signal digital in 8
GND GND3 Signal digital GND digital in 5 … 8 GND
11 DO3.1 0 ... 30 V DC signal digital out 3
11 DO3.2 0 ... 30 V DC signal digital out 3
12 DO4.1 0 ... 30 V DC signal digital out 4
12 DO4.2 0 ... 30 V DC signal digital out 4
DIP 0-0-x-x
0 ... 30 V DC signal
(minus)
analog in 3 Voltage
DIP 1-0-x-x AI3 PT1000 (minus)
analog in 3
Temperature
DIP 0-1-x-x 0 ... 20 mA signal analog in 3 Current
GND GND4 Signal analog earth analog in 3 … 4 GND
DIP x-x-0-0
0 ... 30 V DC signal
(minus)
analog in 4 Voltage
DIP x-x-1-0 AI4 PT1000 (minus)
analog in 5
Temperature
DIP x-x-0-1 0 ... 20 mA signal analog in 6 Current
