Hardware
5-81
Pin assignment of the terminals on the device underside
GND Digital earth signal digital in 1 … 4 GND
1 DI1 0 ... 30 V DC signal digital in 1
2 DI2 0 ... 30 V DC signal digital in 2
3 DI3 0 ... 30 V DC signal digital in 3
4 DI4 0 ... 30 V DC signal digital in 4
GND Signal digital GND digital in 1 … 4 GND
5 DO1.1 0 ... 30 V DC signal digital out 1
5 DO1.2 0 ... 30 V DC signal digital out 1
6 DO2.1 0 ... 30 V DC signal digital out 2
6 DO2.2 0 ... 30 V DC signal digital out 2
DIP 0-0-x-x
0 ... 30 V DC signal
(minus)
analog in 1 Voltage
DIP 1-0-x-x AI1 PT1000 (minus)
analog in 1
Temperature
DIP 0-1-x-x 0 ... 20 mA signal analog in 1 Current
GND GND2 Signal analog earth analog in 1 … 2 GND
DIP x-x-0-0
0 ... 30 V DC signal
(minus)
analog in 2 Voltage
DIP x-x-1-0 AI2 PT1000 (minus)
analog in 2
Temperature
DIP x-x-0-1 0 ... 20 mA signal analog in 2 Current
