Configuration
4-38
4.2 Making the settings
The configuring tool required is Internet Explorer 5.5 or higher.
Starting configuring
• Disconnect the operating voltage.
• Set the DIP switch Options on the IE-GPRS-I/O for the
configuring mode to 1-0-0-0 (ON-OFF-OFF-OFF).
• Connect the serial interconnecting cable (1 : 1).
• Reconnect the operating voltage and wait until the Power LED
lights green and the Status LED flashes red.
• Open the long-distance data transmission connection either by
double-clicking on the shortcut IE-GPRS-I/O you have created on
the desktop or use Start – Settings - Dial-Up
Networking - IE-GPRS-I/O
to establish the connection.
IE-GPRS-I/O stands for the name of the connection.
• Enter the default user name admin - if not stored.
• Enter the default password 12345 - if not stored.
• Start the long-distance data transmission connection.
• In your browser, type http://192.168.1.120/index.htm.
If you have not changed the default settings, the integrated web server
of your IE-GPRS-I/O will be started. The browser will create a dynamic
web site from the configuration data of your IE-GPRS-I/O.
It will take a few seconds until the page is displayed.
