Part Numbering
Mini MegaPAC MMx
A
-1x
B
xxxx
eg. MM4-143605
MM = Mini MegaPAC Prefix
x
A
= number of outputs
1 = Mini MegaPAC Chassis
x
B
= number of modules + FlexPACs
xxxx = assigned by Westcor
ConverterPAC Xx
D
V/x
E
Ax
F
eg. M15V/10A eg. M15V/10ADFI eg. D15V/6.7A-12V/8.3AT
X = ConverterPAC type (For RoHS, add G to current prefix)
M = ModuPAC D = DualPAC R = RamPAC J = JuniorPAC B = BatPAC
(RoHS = GM) (RoHS = GD) (RoHS = GR) (RoHS = GJ) (RoHS = GB)
x
D
= Voltage out
x
E
= Current out (rounded to 1 decimal point)
x
F
= Can be multiple options* (see below)
FlexPAC Fxxaaa-bbb-ccc-ddd
F = FlexPAC xx = pack chassis variations
aaa = voltage setting for output 1 with implicit factor of 10 (103 = 10.3 V)
bbb = output 2 ccc = output 3 ddd = output 4
* ConverterPAC options
B Booster module M Military Grade module
D DC OK or Power Good [1] P Preload
F Full 50-110% output adjustment
[2]
R RAM external
[3]
F1 50-107.5% output adjustment S Trimpot removed for external BatPAC adjustment
F2 50-105% output adjustment T 90-110% output adjustment
[4]
F3 50-102.5% output adjustment T1 90-107.5% output adjustment
F4 50-100% output adjustment T2 90-105% output adjustment
F5 60-110% output adjustment T3 90-102.5% output adjustment
F6 70-110% output adjustment T4 90-100% output adjustment
F7 80-110% output adjustment T5 98-105% output adjustment
F8 90-110% output adjustment T6 100-110% output adjustment
F9 100-110% output adjustment V1 "VXI" low noise (150 mV)15 V < V
OUT
< 24 V output
5
I Industrial Grade module V2 "VXI" low noise (50 mV) V
OUT
< 15 Vdc
K Custom SRF module used V3 "VXI" low noise (1% ripple) for outputs >24 V
[1] D option: Optional for all ConverterPACs EXCEPT the DualPAC, BatPAC, and FlexPAC
[2] F option: Optional for all ConverterPACs EXCEPT the BatPAC, DualPAC and FlexPAC.
Trim Range based on module type and voltage.
[3] R option: When using an external RAM, components such as Autosense resistors and Local Sense
jumpers must be removed before turning on the supply. In addition, in order to insure proper operation,
sense pins must be connected either locally or remotely after the RAM's output. For further information,
contact Applications Engineering.
[4] T option: Optional for all ConverterPACs EXCEPT the BatPAC, DualPAC and FlexPAC. Trim range
determined based on module type and voltage.
[5] V option: Optional ONLY on the ModuPAC, DualPAC and JuniorPAC. N/A on all other
ConverterPACs.
