Input Characterisitcs
Input Voltage
90-132 Vac, 180-264 Vac; 47-500 Hz; 260-380 Vdc
Power Factor (passive)
0.65 typical
Inrush Current (Cold Start)
80 A pk @ 115 Vac
80 A pk @ 115 Vac
Ride Through Time
>20 ms at nominal line, full load
Power Fail
>3 ms warning
Conducted EMI
EN55022 Class A and B
Surge Immunity
EN61000-4-5 Installation Class 3, Performance Criteria B
(Temporary loss of output power may occur which is self recoverable)
Dielectric Withstand
Primary to Chassis GND = 2,121 Vdc
Primary to Secondary = 4,242 Vdc
Secondary to Chassis GND = 750 Vdc
Ouput Characterisitcs
Line/Load Regulation
0.2% max. from 10% to 100% load
0.5% max. from 0% to 10% load
Setpoint Accuracy
1% for standard voltages
2% for special or adjustable voltages
Ripple and Noise
Std. outputs: 2% or 100 mV p-p, whichever is greater, 75% min. load;
VXI options: V1 = (150 mVp-p or less) 15 V < Vout < 24 V outputs
V2 = (50 mVp-p or less) Vout < 15 Vdc
V3 = (1% ripple or less) Vout > 24 V
(VXI options require 15% minimum load)
RamPAC: 10 mVp-p. or 0.15% whichever is greater
FlexPAC: 50 mVp-p
Output Trim Range
50% -110% of nominal voltage VI-200/VI-J00 series modules
90% -110% of nominal voltage VI-200/VI-J00 series modules 10-15 V
Overcurrent Trip Point
105-125% of full load capability of VI-200/VI-J00 series modules
Overvoltage Protection
ModuPAC 115- 135%; N/A to DualPACs, JuniorPACs, BatPACs, RAMPACs
Efficiency
82% typical
Output Power
1,000 W @115 Vac or 230 Vac (strappable)
Environmental Characteristics
Storage Temperature
-40°C to 85°C
Operating Temperature*
-20°C to 45°C, -20°C to 65°C half power
Altitude
Derate 2.6% total output power for each 1,000 ft to a maximum operating
altitude of 15,000 ft. Non-operating storage maximum altitude is 40 K.
Humidity
0 to 95% non-condensing
Safety Approvals
TUV CUE
Standards: CSA-C22.2 No. 60950-00, UL 60950 3rd Edition, EN 60950:2000
CE Mark to the LVD, 73/23/EEC amended by 93/68/EEC
Product Weights
6.25 lbs (2,84 kg) fully configured
0.7 lbs (0,32 kg) ConverterPAC
Warranty
2 years limited warranty.
for complete warranty statement.
* Operating temperature is 45°C using any combination of modules and output voltages as long as the
front end rating is not exceeded. Normal derating applies to half power if the ambient temperature is
20°C hotter.
