TruXedo Deuce Covers manufactured before 12/17/12 - Manual (Page 2)

___ 2 ___
Level side Rails: For optimal latching
performance and cover fit, side rails must
be level. Raise or lower male clamps until
rails are level, then tighten clamps.
LoWeR cLaMP coRRect PosItIon RaIse cLaMP
outWaRd tILt LeveL InWaRd tILt
Clamp configurations shown are for reference only
and are not intended to be standard for all pickups.
Install side Rails: With tailgate closed, align side
rails flush with pickup bed rails and level with
each other. Lightly compress D-seal against
tailgate. Clamp side rails to bed rails, placing
two clamps on fixed portion of rails near ends
of rails. Tighten securely.
clamp
assembly
side
rail
bed rail d
-
seal
tailgate
High Bed Caps -
Adjust side rail height as needed to get a good
seal at front and back of cover.
tighten clamps securely on side rails
before driving vehicle.
WaRnInG !
passenger
’
s
side rail
safety straps
front of
truck box
cover assembly
underbody rail
clamps
washer
cap
screw
driver
’
s
side rail
d
-
seal
end plug
clamp
assembly
sIde RaIL and coveR InstaLLatIon
1
2
