STEMCO AirBAT SST RF User Manual

Page 2

USAGE:

If the Red LED on the AirBAT is blinking, it means that the tire’s air pressure is AT or BELOW the lower pressure threshold.
The threshold is a software function and can be changed with the HandBat reader. There is also a green led that blinks every
5 seconds in the smaller light pipe as an “I’m alive” indicator. The green light can only be seen if the unit is viewed closely
without direct sunlight.

RF INTERROGATION:

This unit can be read by the BatRF HandBat reader or Gate Reader System. The AirBat SST broadcasts information
(pressure and serial number) approximately every 2.5 seconds. For the Gate Reader System, a loop imbedded in the ground
activates the AirBAT SST and prompts it to transmit data. Finally, the BatRF, Driver Alert System (DAS) can be used in
conjunction with the AirBAT SST tire pressure sensor. All of the above mentioned equipment will operate with both single,
dual tire and SST AirBAT tire pressure sensors.

CERTIFICATIONS:

TThis unit complies with FCC Part 15. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

FCC ID: SRA-816

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy. If not installed and used in accordance with the
instructions it may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

This product meets the applicable Industry Canada technical specifications/Le present materiel est conforme aux specifications
techniques applicables d’Industrie Canada. IC:7413A-8150200

NOTE:

The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to

this equipment. Such modifications could void the user’s authority to operate the equipment. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

IMPORTANT NOTES:

This unit contains a Lithium-Thionyl Chloride battery and should be disposed of according to local regulations. The battery
contains less than 1 gram of lithium and is therefore classified as a non-hazardous product. Lithium-Thionyl Chloride batteries
contain no poisonous materials and do not present environmental hazards when properly disposed of.
