OPERATION:

If the LED/light on the AirBAT is blinking, it means that the tire’s air pressure is AT or BELOW the lower pressure threshold.
The blink pressure is defined by the last 3 numbers of the AirBAT part number. The threshold is a software function and can
be changed with the HandBAT reader.

MAINTENANCE:

The AirBAT is a low maintenance product; however it is recommended that the valve stem gasket be changed at the regular
maintenance interval for the tires (i.e. when you replace a tire at the end of tread life). Gaskets are available from STEMCO
(PN: 810-0050) in packages of 24 each.

RF INTERROGATION:

This unit can be read by any BatRF reader such as the HandBAT or Gate Reader System. The AirBAT broadcasts information
(pressure and serial number) approximately every 2.5 seconds. For the Gate Reader System, a loop imbedded in the ground
activates the AirBAT and prompts it to transmit data. Finally, the BatRF Driver Alert System (DAS) or Tractor Interface
Module (TIM) may be used in conjunction with the AirBAT tire pressure sensors to provide in-cab driver notification and off-
board communication of data. All of the above mentioned equipment will operate with single, dual and steer tire AirBAT tire
pressure sensors.

CERTIFICATIONS:

This unit complies with FCC Part 15. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

FCC ID: SRA-816

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy. If not installed and used in accordance with the
instructions it may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

This product meets the applicable Industry Canada technical specifications/Le present materiel est conforme aux specifications
techniques applicables d’Industrie Canada. IC:7413A-816

NOTE:

The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to

this equipment. Such modifications could void the user’s authority to operate the equipment. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

IMPORTANT NOTES:

This unit contains a Lithium-Thionyl Chloride battery and should be disposed of according to local regulations. The battery
contains less than 1 gram of lithium and is therefore classified as a non-hazardous product. Lithium-Thionyl Chloride batteries
contain no poisonous materials and do not present environmental hazards when properly disposed of.

WARRANTY INFORMATION:

All warranty returns may be sent to:

an EnPro Industries company

TS 16949

STEMCO, BAT RF, and AirBAT are all registered

trademarks of STEMCO LP © 2014 P/N 093300081

StemcO - USA

P.O. Box 1989
Longview, TX 75606-1989
(903) 758-9981 • 1800-527-8492
FAX: 1-800-874-4297

www.stemco.com

StemcO - cAnAdA

5650 Timberlea Blvd. Unit B
Mississauga, ON L4W 4M6
(905) 206-9922 • 877-232-9111
FAX: 877-244-4555

STEMCO
300 Industrial Blvd.
Longview, TX 75691
Attn. Warranty Dept.
