Maximum Weight Limits
Shelves: 40 lbs. (18 KG) each
Cabinet: 150 lbs. (67 KG) total
40147-0910
4 12
4.
Upon completion of wall mounting,
install the doors. First insert the fixed
hinge pin located at the top of the door
into the plastic hinge bushing hole in
the top of the cabinet. Position the
bottom of the door over the bottom
plastic hinge bushing hole and insert
the removable hinge pin.
Assemble the handles to the doors.
Install the shelves using 4 shelf clips
each. (See illustration)
Snap the nameplate until flush on the
left door.
LEFT DOOR
RIGHT DOOR
PLASTIC HINGE
BUSHING
FIXED HING PIN
SHELF (2)
4
Shelf Assembly
KEEP ALL 4 SHELF CLIPS AT THE SAME LEVEL
Shelf Assembly
Secure Shelf Clip
Position Shelf Clip
