1.
Position the right side and left side
panels as shown. Each side panel
(right and left) has a top end, bottom
end, front side and back side so it is
important to position each panel as
shown in the illustration.
Assemble the top and bottom to the
side panels with 6 screws on each
panel. Do not over tighten the
screws.
2.
Starting at the bottom, screw the 2 back panels
to the cabinet back using 6 screws each. Do
not over tighten the screws.
40147-0910
2 12
1
TOP
BOTTOM
RIGHT
SIDE
LEFT
SIDE
These 2 holes
must be towards
the bottom end of
the side panel
These 2 holes
must be towards
the bottom end of
the side panel
These holes must
be towards the back
for both side panels
Rectangle
Rectangle
2
BACK (2)
