Technical Specification
Communication ports
COM1 IR Communication port PM180 device Only
Optional Optical Communication port
Max. Baud rate 19.200 kb/s
Protocols Modbus or DNP3.0
Isolation 2500 V
AC
@ 1 mn
COM2 Serial Communication port Device COM port
basic RS-485 Max. Baud rate 115.2 to 480 kb/s
Isolation 4000 V
AC
@ 1 mn
RS-485 Maximum length cable 1000m
Protocols Modbus RTU
Connection DB-15
ETHERNET Multiple device Communication port RGM180-G3 only
10/100Base-T
Basic Built-in network communication port with PoE ability
Wired LAN communication port with auto-negotiation IEEE 802.3
Ethernet port Baud rate
10/100 Mb/s
Protocols Modbus/TCP
ETH port Isolation 1.5 KVAC @ 1mn
ETH connector Standard RJ-45
USB Built-in USB Communication port DISPLAY Panel
Basic - Device (default)
USB communication port Full speed Device
USB port Baud rate 12 Mb/s
Protocols
Modbus RTU/ASCII and
DNP3.0
USB device port Isolation (Remote display) 1500 KVAC @ 1mn
USB device port Isolation (Local display) 4000 KVAC @ 1mn
USB connector DISPLAY Panel
USB type A, vertical mount,
straight
DISPLAY Panel Display
Touch-Panel LCD
graphic display, 1 Wh
pulse led, IR port and
USB Device/Host
connector Type A size 5.7”
resolution 320 x 240 dots
Type TFT – color with Touch Panel
Outline dimensions 131mm (W) x 102mm (H) x
14.5mm (D)
Active area 115.2mm (W) x 86.4mm (H)
Operating temperature -20°C - +70 °C
Storage temperature -30°C - +80 °C
Non-volatile
memory For energy and tariff registers logging, EV-PQ-DATA-
WV log Basic 256MB
