Appendix: Technical Specifications 29
Standards Compliance
EMC ANSI C12.1 Reference: IEC 61000
Surge – IEEE C62.41.2-2002
100kHz ring wave
1.2/50 µs – 8/20 µs 6kV / 0.5kA
6kV / 3kA
Magnetic field – ANSI C12.1
FTB – IEC 61000-4-4, level 4 4kV – measuring inputs
2kV – I/O and com.
SWC – IEEE C37.90.1 2.5kV – measuring inputs,
I/O an com.
Electromagnetic RF Fields – ANSI C12.1 20V/m @ 200kHz – 10GHz
Immunity
ESD - IEC61000-4-2 15KV/– air/contact
Emission Radiated / Conducted - FCC/CFR 47 p.15 Class B
ANSI C12.1
Safety
Insulation, ANSI C12.1 2.5 KV r.m.s. @ 1mn
Mechanical Shock - IEC 60068-2-27
:1987 / ANSI C12.1: 2008 15g @ 11ms
Mechanical Vibration - IEC 60068-2-6
:1987 / ANSI C12.1: 2008
0.5g @ 30-350 Hz
Transportation drop and vibration – ISTA
1A / ANSI C12.1
Operational temperature – ANSI C12.1 -40 ºC to 75 ºC
Storage temperature – ANSI C12.1 -40 ºC to 85 ºC
Environment
Humidity – ANSI C12.1
Measurements
and Accuracy ANSI C12.1
Active Energy measurement - ANSI
C12.20 class 10/20
Class 0.2S
PQ methods – IEC 61000-4-30 Class A
Harmonics & Interharmonics
measurements – IEC 61000-4-7 Class I
Flicker measurements – IEC 61000-4-15 Class I
Power Quality
Report – EN50160
