Salsbury industries – Salsbury Industries 3800 Surface Mount Enclosures For 3700 Series 4C Front Loading Horizontal Mailboxes User Manual
Page 3
The vertical flanges along the two (2) sides of the mailbox unit use
variable quantities of screws depending on the height of the
enclosure. The largest height enclosure is shown and uses seven
(7) screws (provided) on each side. There should be a screw
installed in each slotted hole. See Fig. 7 and Fig. 8.
Fig. 8
SALSBURY INDUSTRIES
1010 East 62
nd
Street, Los Angeles, CA 90001-1598
Ph: 1-800-624-5269 Int’l Ph: 323-846-6700
Fx: 1-800-624-5299 Int’l Fx:
323-846-6800
www.mailboxes.com [email protected]
Installation instructions are provided as general guidelines. It is advised that a professional installer be consulted. Salsbury Industries assumes no product assembly or installation liability.
Copyright © 2011 Salsbury Industries. All rights reserved. (P/N 380001, Rev. 12, 3/2/2011) Page 3 of 3
Fig. 7
Mounting
Screw
Location
Mounting
Screw
Location
RIGHT
MASTER
DOOR
LEFT
MASTER
DOOR
Type B
Type B
=============================================================================================
Completed Installation
Close and latch the master door(s) and all compartment doors.
Fig. 9
