3. names and functions for each part, Front panel and character lcd – RKI Instruments RM-5000 Series Indicator/Alarm Unit User Manual
Page 10
3 Product Components
3-3. Names and functions for each part
RM-5000
- 10 -
3-3. Names and functions for each part
(8) Second
alarm
lamp
(9) Fault
lamp
(7) First alarm lamp
(6) Power
lamp
(19) Maintenance
port
(1) Power
switch
(10) Gas concentration
digital value display
(2) MODE
key
(3) ALM2/▲ key
(4) ALM1/▼ key
(5) TEST/SET
key
(13) Full scale value
display
(12) Gas name and
message
display
(14) Unit display
(11) Gas concentration
bar meter display
(17) Digital
communication
display
(15) Maintenance
display
(16) Inhibit display
(18) Double range
display
(20) Current/voltage
display
