4 Replacement of Consumable Parts
GX-8000
- 22 -
(4) Using an opposite procedure to the above, install the sensor rubber seal and fix the sensor cover.
Screw tightening torque: 5 to 5.5 kgf･cm (49 to 54 N･cm)
For the stable operation of the gas monitor and safety, a qualified service engineer is required to take care
of replacement of the parts that requires high expertise. Please contact RIKEN KEIKI.
Sensor
Sensor
rubber seal
Install the rubber seal
so that the concave
part covers the sensor.
Install the sensor cover
horizontally so as not
to warp the sensor
rubber seal.
