Transport, scope of delivery, installation
12
Pos : 5. 18.1 /00005 Ü berschrif ten/ 1. 1 Ü bersc hrift en/ 1.1 Übersc hrift en BD A/ 11 T ypensc hild Besc hreibung @ 3\ mod_1280933953941_9. doc @ 22302 @ 2 @ 1
3.6 Type plate description
Pos : 5. 18.2 /00003 St andard Kapit el/ General M odul T ypens chil d @ 3\ mod_1280931092443_9. doc @ 22278 @ @ 1
Fig. 1: Type plate lettering
1 Device designation
2 Year of production
3 Part number
4 Serial number
5 Manufacturer’s address
6 CE marking
7 Disposal label
8 Bar code
9 Power version
10 Mains frequency
11 Capacity
12 Amperage
13 Number of fuses
14 Fuse type and fuse strength
In the case of questions please provide the device designation (1) or the part
number (3) and the serial number (4) of the device.
