Operating the machine
28
Fig. 18: Rear view
5.3 Summary table of device parts
Element Description Function
A
Display and control unit:
See below for explanations Time preselection, frequency preselection and
starting/stopping the machine
B Nitrogen gas outlet Outlet for gaseous nitrogen
C Counterweight left Counterweight for the cooling jacket with grinding
jar
D Cooling jacket
Forms the cooling system together with the
grinding jar (T)
E Hood Closes the grinding chamber
F Opening aid
Can be mounted on the grinding jar cover for
simple removal of the grinding jar
FA Support for opening aid Storage of the opening aid
H Fan Ventilates the motor and the interior of the mill
I Caution remove mains plug sign Safety instruction
J Type plate Information about the device and connected loads
K ON / OFF switch Switches the device on and off
L Fuse drawer Accommodates two glass fuses
M Connector Connector for the mains lead of the device
N Cooling agent connection Connection for liquid nitrogen
O RS232 interface Enables updating of the operating software
P Observe operating instructions sign Safety instruction
R Condensation collecting filter
Collects the condensation from the cooling system
and allows it to evaporate
S Drip tray Housing protection
T Grinding jar
Forms the cooling system together with the cooling
jacket (D)
