RaySafe Solo User Manual
Page 18
Calc. delay
defined as the dead time after end trig, before data is calculated. default is
0.5 s but it is recommended to use a longer delay when measuring on pulsed
fluoroscopy where the time between pulses may exceed 0.5 s. (0.5, 2, 4, 6, 7 s)
Backlight
display lighting option. (off, 2, 5, 10 s, on)
Auto Power Off
never, or after 5, 20, 60 minutes of inactivity.
Info
displays the serial number (S/n) and firmware version of the connected detector
and the RaySafe Solo base unit and the calibration date for the sensor. there is
also a possibility to reset the instrument settings to factory defaults.
temperature and pressure values are shown only in the RaySafe Xi View, not on the RaySafe Solo base unit
display.
18
RaySafe Solo User Manual – Ct Measurement
