2. MEASURE MODE
After an offset adjustment, the instrument is in MEASURE MODE. the displayed values are updated after each
exposure, or continuously after 4 seconds of fluoroscopy.
kVp
kVp (for the R/f high, RAd or dent high sensor at adequate signal levels) or kV (R/f
low or dent low).
(not available on RaySafe Solo dose.)
Dose
Gy (Air kerma, free in air) or R (exposure)
Dose rate
Gy or R per s, m or h
Time
ms, s
HVL
mm Al (only with optional hVl kit)
Pulses
pulses
Total filtration
mm Al (included in the optional hVl kit)
mAs
mAs (requires RaySafe Solo R/f with mAs)
mA
mA (requires RaySafe Solo R/f with mAs)
3. SETUP MENU
press SELECT to enter the SETUP MENU (from MEASURE MODE) and STEP to step between setup
parameters.
