2000-B Pick-Up Reel
Pre-Delivery Checklist
Perform these checks and adjustments prior to delivery to your customer. See the Operator's Manual for
adjustment details.
CAUTION: Carefully follow the instructions given. Be alert for safety related messages which
bring your attention to hazards and unsafe practices.
Reel Serial Number __________________
Check for shipping damage or missing parts. Be sure all shipping dunnage is removed.
Grease all plastic bearings during assembly and grease center tube bearings at end supports.
Set cam arm in the “X” position.
Ensure cam arm bolts have nut on bearing side.
Set finger pitch in third notch from the top and use the top range slot.
Set reel fore-aft to center the reel over the cutterbar.
Check finger clearance to cutterbar:
Under 21’ header – ¾ “ (20 mm), 21’ – 1 ¼” (30 mm), 25’ – 1 ½” (40 mm), 30’ – 2” (50 mm)
Recommended reel speed is 10% above ground speed.
Date Checked:
Checked by: __________________
