REPAIR PARTS
REF PART
DESCRIPTION QTY SERIAL
NUMBER NUMBER
1
27171 DISC - arm................................................................................................ A/R
2 35017 ARM - reel................................................................................................. A/R
3 48083 BEARING HALF - bat ............................................................................... A/R
4 27166 STRAP - bearing ...................................................................................... A/R
5 48008 BAT - reel, 54" (1380 mm)........................................................................ A/R
48009 BAT - reel, 60" (1535 mm)........................................................................ A/R
48010 BAT - reel, 66" (1690 mm)........................................................................ A/R
48011 BAT - reel, 72" (1840 mm)........................................................................ A/R
6 48070 CRANK - L/H, long ................................................................................... A/R
48071 CRANK - R/H, long................................................................................... A/R
48128 CRANK - L/H, short .................................................................................. A/R
48129 CRANK - R/H, short.................................................................................. A/R
7 48095 BAT - INBOARD END, L/H reel - 36' 960 only ............................................. 5
48135 BAT - INBOARD END, L/H reel - 36' 962 only ............................................. 5
48096 BAT - INBOARD END, R/H reel - 36' 960 only............................................. 5
48136 BAT - INBOARD END, R/H reel - 36' 962 only............................................. 5
8 REF COLLAR - shaft, See Mounting Packages ............................................... A/R
9 27984 TUBE - bat connector ............................................................................... A/R
10 27985 FINGER - pick-up, plastic ......................................................................... A/R
11 48086 BEARING - end shield (was 35660) ......................................................... A/R
12 48023 SHIELD - end, 5 bat reel ............................................................................ 10
48024 SHIELD - end, 6 bat reel ............................................................................ 12
13 REF WASHER - flat, see Mounting Packages ................................................. A/R
14 REF SUPPORT R/H - see Mounting Packages ................................................... 1
15 REF SUPPORT L/H - see Mounting Packages .................................................... 1
16 48065 CAM TRACK ................................................................................................ 2
17 48058 RING - cam, L/H, 5 bat reel .......................................................................... 1
48059 RING - cam, R/H, 5 bat reel ......................................................................... 1
48060 RING - cam, L/H, 6 bat reel .......................................................................... 1
48061 RING - cam, R/H, 6 bat reel ......................................................................... 1
18 50184 BEARING - ball......................................................................................... A/R
19 48051 ARM - cam............................................................................................... A/R
20 50185 BEARING - ball......................................................................................... A/R
21 48050 BOLT - shoulder, special .......................................................................... A/R
25 23165 DECAL - 50 hour grease .............................................................................. 2
26 35689 NUT - special, 5/16 inch NC ..................................................................... A/R
27 REF TUBE - main, see listing on page 27 ............................................................ 1
28 REF TUBE - end, L/H, see Mounting Packages................................................... 1
29 REF TUBE - end, R/H, see Mounting Packages .................................................. 1
31 35661 TOOL - finger/adjuster .................................................................................. 1
35 35396 DECAL - reel rotation, left............................................................................. 3
36 35397 DECAL - reel rotation, right .......................................................................... 3
37 26697 REFLECTOR - amber .................................................................................. 2
38 35243 DECAL - CAUTION, general safety.............................................................. 2
39 35282 FINGER - Pick-Up, steel........................................................................... A/R
40 35281 CLIP - steel finger..................................................................................... A/R
A-P Hardware
See Page 27.
NOTE: A mounting parts list was shipped with the mounting package for your particular windrower or
combine. Keep the list with this manual for future reference.
