Page 5
1 - ACU fails to enrol onto the PC (WIRELESS PROBLEMS).
Q The Net2 nano must be in range of a Net2Air bridge. Detailed advice can be found on the website as follows:-
QX AN1095 - Net2 wireless access control < http://paxton.info/974 >
QX AN1096 - How to plan a Net2 wireless installation < http://paxton.info/975 >
2 - Readers/keypads not working.
Q - Software settings - Confirm that the settings of the reader or keypad are correct.
Q - Connections - Check the wiring and integrity of the connectors. If possible, test this reader on the other unit.
Q - Cable - Belden 9540 should be used to extend the reader cable (Max 100 m). Twisted pair alarm cable should
Q not be used. To confirm that a cable extention is not at fault, wire the reader directly to the reader port.
Q - Supply voltage - Confirm that the voltage is within specification. (see table)
Q - User token - Confirm that the user token used for testing is OK by presenting it to a known working reader.
Q - Interference - Confirm whether the reader works when tested 'in hand' and not mounted on the wall. Ensure
Q that readers are not mounted back to back or there is no interference from other local RF devices.
3 - Why are some of the Net2 features (e.g. Fire alarm integration) not available on Net2 nano?
Q Wireless communication is not suitable for safety critical applications.
4 - Net2Air - What does this mean?
Q This is a term to describe the wireless communication protocol used by Paxton products in much the same
Q way as Bluetooth, but the Net2Air protocol is not open. Only Paxton products can use this technology.
Q The Net2Air protocol is based on the standard known as IEEE 802.15.4. It operates at 2.4 GHz and can co-exist
Q with wireless LAN networks and other devices using this frequency such as DECT phones. All Paxton
Q products employ AES128 encryption technology to ensure that all communication remains secure.
Here is the list of topics about this product that receive the most technical support enquiries.
We list them here to help you speed up the installation and trouble shooting process.
10,000
10,000
250
64
1 sec 99,999 sec
50
1
1
2
2
10
1 100
30 m
3,584
11V DC 14.5V DC
120 mA
24V DC
2 A
1.1 A
1 A
500 mA
2.405 GHz
0 °C + 55 °C
105 mm 106 mm 23 mm
200 mm 200 mm 75 mm
Voltage
Relay switchable current
Relay switchable voltage
Operating temperature - Battery limits
Electrical
Environment
Dimensions
PCB Current (depending on activity)
Features
Waterproof
Min
Width Height
Max
Min Max
Depth
Min Max
Number of PIN's
Access levels
Time zones
Alarm output current
Maximum door open time
Doors per ACU
Reader ports per ACU
Readers per port
Keypads per port
ACU's per Net2Air bridge - Recommended
Data retention after total power loss
Events stored in ACU with no server connection
Number of Cards
Number of Codes
Specifications
No
Reader port output current
Control Unit
Plastic Housing
Net2Air bridge per system
Net2Air wireless range
Dedicated lock output current
Carrier frequency
The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596
60 days
