Page 4
A Nano must bind to a Net2Air bridge before it will enrol itself onto the Net2 system. The term 'bind' is used to
denote the fixed relationship between a Nano and its bridge.
Create a user record in the database and assign a Net2 token to the user. If you are not using PROXIMITY tokens
you should still create the user record and assign a token number (Not a PIN) of your choice. These records can
be deleted after the installation is complete.
Connect a PROXIMITY reader to the Nano and then present the same user token previously assigned. (If you are
enrolling a Keypad only unit, enter the token number on the keypad followed by * ) The Nano will then transmit
the token number and wait for a response from a bridge.
If more than one bridge replies, the Nano checks the signal strength and selects the strongest bridge to
communicate with. The Net2 software confirms that the token number is in the database and if so registers this
Net2 nano/bridge binding.
Enrolling a Net2 nano
Software Configuration
Reader: Settings for the Reader and Keypad.
Outputs: Lock, Relay, Alarm. - Selects these outputs to be
used by the Lock, Bell or Alarm functions.
Alarm: Configures the settings for the different alarm types.
Codes: Valid keypad codes can be viewed, added and removed
(This tab is only displayed when a keypad is fitted)
Events: Shows the events for this control unit only.
Access Rights: Lists users who have access through this door.
Name: The reader can be named individually if required.
Reader type: Set the reader type, if applicable.
Keypad type: Set the keypad type, if applicable.
Reader operating mode: Set the operating mode.
Timed operating modes: A different operating
mode can be configured within a time window.
Door name: Name the Door.
Door open time: Set the door open time.
Unlock the Door during: Holds the door unlocked during this
timezone. - Set to 'At No Time' for normal user operation.
Net2 nano reset
The Nano controller holds the address information for the bridge that it is bound with. This will cause problems if
the unit is to be used on another system.
To clear this address information, you need to perform a hardware reset. Link Orange/Mauve on the reader port
and then power cycle the unit.
Make sure that the power is not removed again until after the green OK LED is flashing again. Later versions of
software also flash the reader LED's until the reset process has finished. Remove the Orange/Mauve link.
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
PC Installation
The current specification for compatible PC hardware, network and operating systems is available on our website
at the following link: http://paxton.info/720
