Rev. D 0210 44523 pg 15
Adjusting the Top
WARNING When operating the vehicle without the Quarter Windows,
the Rear Curtain should be rolled up for proper ventilation.
Quarter Windows
To remove the Quarter Windows.
Unzip the rear and top zippers.
Release the plastic strip from the
retainer. Release the Hook and
Loop Fasteners from around the
Vertical Retainer.
Removal of Soft Top for Open Air Driving
When operating the vehicle with the fabric top removed, it is very important that the support-
ing hardware system be disconnected from the windshield bracket and folded flat to the rear
of the vehicle. Wrap the elastic straps around the bows and insert the plastic strip into the
Side Belt Rail. Never operate the vehicle with the fabric removed and the hardware in the fully
erected position.
Quarter
Window
Opening the Sun Roof
Release the Windshield Header Latches and fold the Windshield Retainer
back so that it rests on the center bow and the sport bar.
