Windshield retainer kit, Installation instructions

51209 1
Note: Please read this manual thoroughly before beginning the installation. After completing
installation, keep this manual for future reference.
WINDSHIELD RETAINER KIT
Installation Instructions
PART NUMBER: 51209
Parts List and Hardware Identification
Check off each item
Windshield Retainer - Right,
Qty - 1, PN 225.42
Windshield Retainer - Left,
Qty - 1, PN 225.43
Because of Generic Packaging, extra parts may be included.
#8 x 1/2" Pan Head
Washer Screw - Black,
Qty - 13, PN 200.48
Tools You Will Need
[] A pencil
[] A Phillips head screwdriver
[] A hammer
[] A center punch
[] A 1/8" drill bit and a power drill
CAUTION: A loose windshield retainer may allow the top
to disengage from the windshield, causing damage to the
top and possible injury to the occupants of the vehicle.
Make certain that the windshield retainer is securely
fastened to the windshield at the time of first installation.
Check the tightness of the mounting screws every three
months. (Do not over-tighten.)
Safety Glasses should be worn at all times while installing
this product.
[] Safety Glasses
DO NOT INSTALL THIS PRODUCT ON ANY VEHICLE OTHER THAN THOSE LISTED ABOVE.
This product is only designed for the vehicles listed above. Failure to install this product on the proper vehicle could
cause injury to the vehicle occupants and damage to the product.
CJ5, CJ7, 1986-1995 Wrangler,
Toyota FJ40 Landcruiser 1964-1984
