Pavement Ends 41422 Cab Curtain User Manual
Cab curtain, Parts list and hardware identification, Tools needed

41422 pg 1
Rev. B 0303
Installation Tips
After completing the installation, keep these instructions
for future reference. Before you begin installing this Cab
Curtain, read all instructions thoroughly. Below are a
few tips to make this installation easier.
For a smooth fit:
For ease in installation, this product should be installed
at temperatures above 72 F. Below this temperature,
the fabric may contract an inch or more, making it
difficult to fit to the vehicle.
It is normal for the fabric to contract and wrinkle when
stored in the shipping carton. Within a few days after
the installation, the fabric will relax and the wrinkles will
disappear.
The Cab Curtain may be used in the winter to contain
heat in the front passenger area.
WARNING
This product is designed to enhance the appearance of the
vehicle and to shield the occupants from ordinary weather con-
ditions. Do not rely in any way on the components of this product
to contain occupants within the vehicle, or to protect against
injury or death in the event of an accident. This top will not protect
the occupants from falling objects. Never operate vehicle in
excess of manufacturer’s specifications.
WEAR SEAT BELTS AT ALL TIMES
Read and follow, precisely, all installation instructions provided
when installing top. Failure to do so may result in a poor fitting
top and could place occupants of the vehicle in a potentially
dangerous situation. After installing or reinstalling the top,
check to make sure it has been properly installed.
Cab Curtain
Installation Instructions
For: Wrangler 1980 - 2002
Part Number: 41422
Important Note: The Cab Curtain is custom designed to attach to the leading edge of the Cargo
Cover, sold separately through your dealer, which covers folded soft top bow assemblies.
Parts List and Hardware Identification
#20 Torx Snap Head Screw, Qty - 3
Acorn Locknut, Qty - 3
Cab Curtain
Qty - 1
Footman Loop Kit
Qty - 1
Tools Needed
1/8" Drill Bit and Drill Motor
Phillips Screwdriver
Pencil
Silicone Sealer
Small Parts Kit
Qty - 1
Footman Loop, Qty - 2
#10 x 1/2" Oval Head
Phillips Screw, Qty - 4
