51133 pg 1

Rev. D 1205

Installation Tips

Before you begin installing this top assembly, read all
instructions thoroughly. After completing the installation,
keep these instructions for future reference. Below are a
few tips to make this installation easier.

For a smooth fit:

For ease in installation, the top should be installed at
temperatures above 72

° F. Below this temperature, the

fabric may contract an inch or more, making it difficult to fit
to the vehicle.

It is normal for the fabric to contract and wrinkle when
stored in the shipping carton. Within a few days after the
installation, the fabric will relax and the wrinkles will
disappear.

WARNING

This product is designed to enhance the appearance of the
vehicle and to shield the occupants from ordinary weather con-
ditions. Do not rely in any way on the components of this product
to contain occupants within the vehicle, or to protect against
injury or death in the event of an accident. This top will not protect
the occupants from falling objects. Never operate vehicle in
excess of manufacturer’s specifications.

WEAR SEAT BELTS AT ALL TIMES

Read and follow, precisely, all installation instructions provided
when installing top. Failure to do so may result in a poor fitting
top and could place occupants of the vehicle in a potentially
dangerous situation. After installing or reinstalling the top,
check to make sure it has been properly installed.

Fabric

Replacement Top

Installation Instructions

For: Suzuki Samurai

Part Number: 51133

This Pavement Ends Soft Top requires all factory original equipment hardware to complete the installation.

Note: If you are missing the tension straps and related mounting hardware, please refer to page 2 of these instal-

lation instructions.
