Multiquip T12D50SA - Manual (Page 43)

LT12D50SA LIGHT TOWER • OPERATION MANUAL — REV. #0 (03/16/09) — PAGE 43
GRN
WHT
CB6
15 AMP
AUX.
BREAKER
230 VAC
AUX RECPT.
TB2
WHT
GRN
WHT
CHASSIS
GROUND
WHT
CB4
15 AMP
BREAKER
(LAMP 4)
CB3
15 AMP
BREAKER
(LAMP 3)
CB2
15 AMP
BREAKER
(LAMP 2)
CB1
15 AMP
BREAKER
(LAMP 1)
NEU. 230V IN OUTPUT
BALLAST #4
30µF@440V
CAPACITOR
NEU. 230V IN OUTPUT
BALLAST #3
30µF@440V
CAPACITOR
NEU. 230V IN OUTPUT
BALLAST #2
30µF@440V
CAPACITOR
NEU. 230V IN OUTPUT
BALLAST #1
30µF@440V
CAPACITOR
WHT
NEUTRAL BUS
CB5
30 AMP
MAIN
BREAKER
RED
RED
RED
RED
YEL
YEL
YEL
YEL
BLK
BLK
J1 J2 J3 J4
GRN
BLK
BLUE
BLK
BLK
RED
YEL
BLK BLK BLK WHT WHT BLK WHT
BLK 16AWG
BLUE 16 AWG
RED 16 AWG
YEL 16 AWG
WHT 14 AWG
GRN 16 AWG
WHT
GRN
YEL
YEL
YEL
YEL
6-WIRE COIL CORD
P/N 19955
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK GRN
BLK
T-BAR ASSEMBLY
P/N 19954
CONTROL PANEL/BALLAST
ASSEMBLY P/N 29614
BLK
BLK
BLK
4
3
1 BLK
WHT
BLK
230 VAC
FROM GENSET
NOTES:
C
WIRE SIZE IS 12 AWG UNLESS
OTHERWISE SPECIFIED.
E
D
SOME UNITS MAY HAVE A 47K
½ WATT RESISTOR INSTALLED
ACROSS THE CAPACITOR
TERMINALS. OTHER UNITS MAY
HAVE THIS RESISTOR INTERNALLY
INSTALLED WITHIN THE CAPACITOR.
W
D
WHT
WHT
BLK
BLK
WHT
E CONNECT AUX. POWER RECEPTACLE
TO THESE CONNECTION POINTS.
C
F 6-WIRE COIL CORD P/N 19955
INSTALLED ON UNITS S/N 905512
AND BELOW
F
G
S/N 902625 AND BELOW USE ONLY
SCREW TYPE CIRCUIT BREAKERS
G
LT12D50SA WIRING DIAGRAM — S/N 902625 AND BELOW
