PAGE 12 — LT12D50SA LIGHT TOWER • OPERATION MANUAL — REV. #0 (03/16/09)
SPECIFICATIONS
Table 1. LT12D50SA Specifi cations
Light Tower Model LT12D50SA
Engine Model
Lombardini LDW 1003
Diesel Engine
Weight (Dry) 1,550 lbs. (700 kg.)
Support Points 5
Wind Stability with Genset 65 mph (80.46 kph)
Lamps Four 1,000-Watt Metal Halide
Lumens 440,000
Light Coverage 5 to 7 acres
Light Termination 4 x 3-pin QD plug
Generator Specifi cations
Twist-Lock Circuit Breaker (Amps) 30 A
Continuous Output (Watts) 6,000 W
Noise Level @ 23 ft. (7 m) 73 dB
Trailer Specifi cations
Jackstand Capacity 2,000 lbs. (907 kg.)
Hitch Type 2-in. Ball (Optional Pintle Kit available)
Tire Size 13 in. (330 mm.)
Tire Rim Size 13 x 4.5 in. (330 x 114 mm)
Axle Capacity 2,000 lbs. (907 kg.)
Hub Type 5-Lug
Suspension Type 3-Leaf
Electrical Tail-light Connector 4-Wire
Winch Capacity 1,500 lbs. (680 kg.)
Winch Rope Wire 3/16 in.
