PAGE 12 — DCA20SPXU2D 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/25/11)
Table 1. Generator Specifi cations
Model DCA-20SPXU2D (Digital)
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Series
Phase Single-Phase 3-Wire
Standby Output 22 kW
Prime Output 20 kW
Voltage 120/240V
Frequency 60 Hz
Speed 1800 rpm
Power Factor 1.0
Aux. AC Power Single Phase, 60 Hz
Sound Level db (A) full Load
at 23 ft. (7 meters)
63
Weight (No Fuel) 1,412 lbs. (640 kg.)
Weight (Fuel) 1,563 lbs. (709 kg.)
Table 2. Engine Specifi cations
Model ISUZU BV-4LE2 Interim Tier 4
Type 4 cycle, water-cooled, direct injection
No. of Cylinders 4 cylinders
Bore x Stroke 3.34 in. x 3.77 in. (85 mm x 96 mm)
Displacement 133 cu. in. (2,179 cc)
Rated Output 34.3 HP/1800 RPM
Starting Electric
Coolant Capacity 1.74 gal. (6.6 liters)
Lube Oil Capacity 2.25 gal. (8.5 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 17 gal. (65 liters)
Fuel Consumption
1.66 gal. (6.3 L)/hr at full load 1.21 gal. (4.6 L)/hr at 3/4 load
0.85 gal. (3.2 L)/hr at 1/2 load 0.58 gal. (2.2 L)/hr at 1/4 load
Battery 12V 53Ah x 1
SPECIFICATIONS
