Sp2S20h paVeMeNT SaW • operaTioN MaNual — reV. #1 (02/17/12) — page 19
cOMpOnents
Figure 2. SP2S20H Components (Left Side)
11
7
LEFT-SIDE
1
2
3
5
6
8
10
12
13
14
9
4
1. raise/lower Crank handle — Physically orients saw
(raises or lowers) depending on cranking direction
(clockwise or counterclockwise). Turning the handle
clockwise lowers the saw while turning the saw counter-
clockwise raises the saw.
2. Transmission engage/Disengage lever — Forward
locking position engages transmission. Rear Locking
position disengages transmission from rear axle and
permits "free wheeling".
3. Water oN/oFF Valve — oN position opens valve and
permits water to flow from source through saw water
hose. oFF position closes valve and halts the flow of
water.
4. WaTer TaNK oN/oFF ValVe —Turns on/off the flow
of water from the internal water tank.
5. Blade removal Tool — Used to remove saw blade
from unit.
6. Belt Cover — Covers the drive shaft belt, engine pulley
and the hydraulic transmission belt.
7. Drive-Shaft pulley guard — Covers the drive shaft
pulley.
8. Balance Weight — Helps keep the blade running in
the cut while the saw is traveling through concrete.
9. Saw Blade — Use only MQ recommended blades. This
unit can use 14, 16, 18, and 20-inch blades.
10. Saw Blade guard — Covers the saw blade during
cutting operations and allows water hoses to be
connected to the cover for wet cutting.
11. pointer arm — Front pointer wheel assists in straight
tracking. Lifts up for storage and pivots down for use.
12. Fuel Tank — Holds unleaded gasoline.
13. lifting Bale — Allows for easy lifting and transporting
of the saw.
14. Choke Knob — Push down to close choke when
operating the saw in cold weather conditions, pull up
to open choke in normal weather.
